Beschrijving
Introducing the ZWO ASI 290MM (mono) 1936×1096 2.9µm
The ZWO ASI 290MM (mono) 1936×1096 2.9µm features the new 1.28″ 2.13Mp Sony IMX290LQR / IMX291LQR back-Illuminated CMOS sensor with 2.9 µm pixels.
Improved visible light and near infrared sensitivity. This camera supports Full HD 1080p and also has an anti-reflective (AR) optical window. The camera comes with a 2.5mm ‘all sky’ lens that can provide an almost 170° view of the sky.
Specifications of the ZWO ASI 290MM (mono) 1936×1096 2 9µm
- Resolution 2.13 MP – 1936 x 1096 PX
- Pixel size 2.9 µm
- Sensor: 1/3″ CMOS IMX291
- Including 2.5 mm all-sky lens for spectacular overview images (170°) – with T2 connecting thread
- Up to 170 FPS (frames per second)
- Extremely low readout noise
- Short download time through USB 3.0
- Extremely compact – only 62mm x 41mm
- Autoguiding interface (ST-4)
- AR protect window built-in – full transmission also in IR
Supported Resolutions and FPS
The ASI290MM supports with USB2.0 with the following FPS values (maximum number of images per second) per resolution:
- 1936×1096: 20.4
- 1280×960: 35.3
- 640×480: 141.5
- 320×240: 355.9
- 2X2Bin :968×548: 20.4
The ASI290MM supports USB2.0 with the following FPS values (maximum number of images per second) per resolution (12bit/10bit):
- 1936×1096: 82.2/170
- 1280×960: 93.6/193.9
- 640×480: 184/381.2
- 320×240: 355.9/737.5
- 2X2Bin :968×548: 82.2/170
Specificaties algemeen
Staat:
New
Merk:
ZWO
Serie:
ASI290
Garantie:
2 years
Artikelnummer Ganymedes:
ZWO-ASI290MM
Artikelnummer fabrikant:
ASI290MM
Specificaties product
Sensor soort:
CMOS
Sensor maat:
1/3"
Sensor afmeting:
5.6 x 3.2
Sensor type:
IMX290/IMX291
Sensor diagonaal (mm):
6.46
Kleur of Mono:
Monochrome
Megapixel (M):
2.1
Resolutie:
1936×1096
Pixelgrote (micron):
2.9
Maximaal beelden per seconde (FPS):
20.4
Geheugen:
No
Aantal bit (ADC):
12
Beschermglas:
AR coated window
Sluiter:
Rolling Shutter
Belichtingstijd:
32µs-2000s
Uitlees ruis (read noise):
1.0e
QE piek:
80%
Full well:
14600e
Actieve koeling:
No
Aansluiting op computer:
USB 3.0
Aansluiting op telescoop:
1.25
ST4 aansluiting:
Yes
Meegeleverde adapters:
2″ / 1.25″ / M42X0.75
Meegeleverde kabels:
USB3.0
Lengte (mm):
36
Diameter (mm):
62
Gewicht (kg):
0.120
Backfocus (mm):
12.5
Toepassing:
AllSky and Meteorites, auto guider, Moon and planets
Filterwiel ingebouwd:
No
Voeding:
Via USB
Toepassing
Geschikt voor maan en planeten:
Excellent
Geschikt voor nevels en sterrenstelsels:
Moderate
Geschikt voor zon:
Excellent
Geschikt voor autoguiding:
Moderate
Geschikt voor All-Sky:
Excellent
Geschikt voor kinderen:
Nee
Geschikt voor beginnende gebruiker:
Nee
Geschikt voor gevorderde gebruiker:
Ja
